IOTA DLS 27V 25A Charger & Converter
The IOTA DLS 27V 25A is a commercial-grade power converter and battery charger designed specifically for 24VDC systems. Utilizing high-efficiency Switch-Mode Technology, this unit delivers exceptionally clean DC output, making it the ideal choice for sensitive off-grid electronics, telecommunications equipment, and heavy-duty battery maintenance.
Built for reliability in demanding environments, the DLS Series features Proportional Fan Control for "whisper-quiet" operation and a compact chassis that handles fluctuating generator input (108-132VAC) without compromising its steady 27.2VDC output.
Technical Specifications
| Specification | Data Rating |
|---|---|
| Product SKU | DLS/M-27V-25A |
| Voltage System | 24V Nominal DC |
| Max Continuous Output | 25 Amps |
| DC Output Voltage | 27.2V (DC) Nominal |
| Continuous Power | 675 Watts |
| Input Voltage Range | 108 - 132 VAC |
| Typical Efficiency | > 80% |
| Dimensions | 9.67" x 6.7" x 3.4" |
| Weight | 5.0 lbs |
| Certifications | UL & CUL Listed |
Key Performance Features
Clean Power Delivery
Tight line/load regulation prevents erratic DC output, protecting sensitive computers and off-grid appliances from unexpected surges.
Battery Compatibility
Optimized for Deep-Cycle, VRLA, Gel, AGM, and Flooded Lead-Acid. Compatible with Lithium (LiFePO4 ™) when used with IOTA IQ controllers.
Built-In Protection
Equipped with thermal overload protection, cycle-by-cycle peak limiting, and external reverse polarity protection via blade-type fuses.
Scalable Power
Units can be wired in series for higher voltage requirements or in parallel for increased amperage capacity.
Smart Charging Expansion
The DLS 27V 25A features a Dual Voltage Jack for manual toggling between Float (27.2V) and Absorption (28.4V) charges. For fully automated 4-stage charging, simply plug in an optional IOTA IQ Smart Controller:
- IQ4 - Standard 4-stage charging for most Lead-Acid banks.
- IQ-AGM - Tailored profiles for AGM battery technology.
- IQ-LiFePO - Precision voltage delivery for Lithium batteries with internal BMS.
- IQ-Turbo - Rapid bulk charging for frequently cycled systems.
Premium DC Power and Charging Solutions for the Modern Cabin.
IOTA DLS 27V 25A
